Vanadium

50.94

The chemical element vanadium is classed as a transition metal. It was discovered in 1801 by Andres Manuel del Rio.

Data Zone

Classification:	Vanadium is a transition metal
Color:	silvery
Atomic weight:	50.9415
State:	solid
Melting point:	1920 ^oC, 2193 K
Boiling point:	3400 ^oC, 3673 K
Electrons:	23
Protons:	23
Neutrons in most abundant isotope:	28
Electron shells:	2,8,11,2
Electron configuration:	[Ar] 3d³ 4s²
Density @ 20^oC:	6.1 g/cm³

Show more, including: Heats, Energies, Oxidation,
Reactions, Compounds, Radii, Conductivities

Atomic volume:	8.78 cm³/mol
Structure:	bcc: body-centered cubic
Hardness:	7.0 mohs
Specific heat capacity	0.49 J g^-1 K^-1
Heat of fusion	20.90 kJ mol^-1
Heat of atomization	514 kJ mol^-1
Heat of vaporization	459 kJ mol^-1
1^st ionization energy	650.3 kJ mol^-1
2^nd ionization energy	1413.5 kJ mol^-1
3^rd ionization energy	2828 kJ mol^-1
Electron affinity	50.7 kJ mol^-1
Minimum oxidation number	-1
Min. common oxidation no.	0
Maximum oxidation number	5
Max. common oxidation no.	5
Electronegativity (Pauling Scale)	1.63
Polarizability volume	12.4 Å³
Reaction with air	mild, w/ht ⇒ V₂O₅, VN
Reaction with 15 M HNO₃	mild
Reaction with 6 M HCl	none
Reaction with 6 M NaOH	none
Oxide(s)	VO, V₂O₃, VO₂, V₂O₅ (vanadium pentoxide)
Hydride(s)	VH, VH₂
Chloride(s)	VCl₂, VCl₃, VCl₄
Atomic radius	134 pm
Ionic radius (1+ ion)	–
Ionic radius (2+ ion)	93 pm
Ionic radius (3+ ion)	78 pm
Ionic radius (1- ion)	–
Ionic radius (2- ion)	–
Ionic radius (3- ion)	–
Thermal conductivity	30.7 W m^-1 K^-1
Electrical conductivity	4 x 10⁶ S m^-1
Freezing/Melting point:	1920 ^oC, 2193 K

Vanadium metal with oxide layer. Photo by Tomihahndorf.

Discovery of Vanadium

Dr. Doug Stewart

Vanadium was discovered in 1801 by the Spanish scientist Andres Manuel del Rio.

Del Rio discovered the new element in brown lead ore (now known to be the mineral vanadinite, Pb₅[VO₄]₃Cl) in New Spain (Mexico).

Del Rio had moved to Mexico as a professor of Chemistry and Mineralogy at the Royal School of Mines, Mexico City.

He named his new element panchromo or panchromium meaning ‘all of the colors’ because of the wide range of colors he had found when investigating the element’s salts.

He then renamed the element eritrono or erythronium, from the Greek word eruthros, meaning red. The new name was inspired by the red color which was seen when Group 1 or Group 2 oxide salts of the new element – for example sodium vanadium oxide – were heated or acidified. ^(1),(2),(3)

In 1805 the French chemist Hippolyte-Victor Collet-Descotils examined the lead ore and announced that erythronium was actually impure chromium – an analysis which, unfortunately, del Rio accepted.

Nothing more was heard of the element until 1830, when Nils Gabriel Sefström in Stockholm, Sweden, found a new metal in a Swedish iron ore.

He called this new element vanadium after ‘Vanadis’ the Scandinavian goddess of beauty because of the beautiful multicolored compounds formed by the metal.⁽⁴⁾

In the same year, German chemist Friedrich Wöhler reinvestigated the Mexican lead ore and found that vanadium was identical to del Rio’s erythronium.⁽⁵⁾

The metal was first isolated by Sir Henry E. Roscoe in 1867, in Manchester, England, by reducing vanadium chloride with hydrogen.

The vanadium mineral roscoelite was named in honor of Rocoe’s work.^{(4), (6)}

Vanadium’s Periodic Table Neighborhood
Vanadium’s discovery in 1801 was initially disregarded because it was thought to be impure chromium, which sits on vanadium’s right in the periodic table. Of course, in 1801 the concept of the periodic table had not been born.

Vanadium’s colorful oxidation states: +2 is lavender; +3 is green; +4 is blue; +5 is yellow. When he saw these colors, Andres Manuel del Rio first decided to call the new element panchromium meaning ‘all of the colors.’ You can see these colors being generated by chemical reactions in the short video below. Photo by Steffen Kristensen.

Vanadium is named after the Scandinavian goddess of beauty because of its multiple colors. Watch it change colors as it changes oxidation state with shaking.

An SR-71B from NASA’s Dryden Flight Research Center, capable of flying at more than 2,200 mph and at altitudes of over 85,000 feet. A titanium-aluminum-vanadium alloy is used for jet engines and for high-speed aircraft. (Photo credit: NASA)

Appearance and Characteristics

Harmful effects:

Although vanadium is an essential trace element for some creatures a number of its compounds are toxic.

Generally, the higher the oxidation state of vanadium, the more toxic the compound.

Characteristics:

Vanadium is a bright white, soft, ductile metal with good structural strength.

Vanadium is resistant to attack by alkalis, hydrochloric acid, sulfuric acid, and salt water.

When present in compounds, vanadium exists mostly in the oxidation state V.

The metal oxidizes in air at around 660 ^oC to the pentoxide (V₂O₅).

Uses of Vanadium

The main use of vanadium is in alloys, especially with steel.

85% of all the vanadium produced goes into steel, 10% goes into alloys of titanium and 5% into all other uses. ⁷

A small amount of vanadium adds strength, toughness, and heat resistance.

It is usually added in the form of ferrovanadium, a vanadium-iron alloy.

Vanadium steel alloys are used in gears, axles and crankshafts.

Titanium-aluminum-vanadium alloy is used in jet engines and for high-speed aircraft.

Vanadium foil is used in cladding titanium to steel.

Vanadium-gallium tape is used in superconducting magnets.

Vanadium pentoxide is used in ceramics and as a catalyst for the production of sulfuric acid.

The first extensive industrial use of vanadium metal was over a century ago in the vanadium-steel alloy chassis of the Ford Model T car.

A 1908 advertisement for the Model T read, “Vanadium steel, the strongest, toughest and most enduring steel ever manufactured, is used throughout the entire car.”

Abundance and Isotopes

Abundance earth’s crust: 120 parts per million by weight, 50 parts per million by moles

Abundance solar system: 400 parts per billion by weight, 9 parts per billion by moles

Cost, pure: $220 per 100g

Cost, bulk: $2.70 per 100g

Source: Vanadium is not found free in nature but is found combined in about 65 different minerals. Vanadium is also found in bauxite and in fossil fuel deposits. Commercially, production of the metal is by calcium reduction of the pentoxide.

Isotopes: Vanadium has 18 isotopes whose half-lives are known, with mass numbers 43 to 60. Naturally occurring vanadium is a mixture of two isotopes, ⁵⁰V and ⁵¹V with natural abundances of 0.2% and 99.7% respectively.

References

Dieter Rehder, Bioinorganic Vanadium Chemistry, 2008, Wiley, p2
Ariosto Aguilar Mandujano, Andres Manuel del Rio, Educator
B. Smith Hopkins, Chemistry of the Rarer Elements, 1923, D.C. Heath and Company, p205
J.W. Mellor, A Comprehensive Treatise on Inorganic and Theoretical Chemistry, Volume IX, 1929, Longmans, Green and Co., p714
Sydney Marks, A Text-book of Inorganic Chemistry Volume VI. Part III., 1929, Charles Griffin & Company Limited, p12
Per Enghag, Encyclopedia of the Elements: Technical Data – History – Processing – Applications, 2008, John Wiley & Sons, p542
François Cardarelli, Materials Handbook: A Concise Desktop Reference, 2008, Springer, p342
