Niobium Element Facts

Data Zone | Discovery | Facts | Appearance & Characteristics | Uses | Abundance & Isotopes | References
41
Nb
92.91

The chemical element niobium is classed as a transition metal. It was discovered in 1801 by Charles Hatchett.

Data Zone

Classification: Niobium is a transition metal
Color: silvery-white
Atomic weight: 92.9064
State: solid
Melting point: 2477 oC, 2750 K
Boiling point: 4744 oC, 5017 K
Electrons: 41
Protons: 41
Neutrons in most abundant isotope: 52
Electron shells: 2,8,18,12,1
Electron configuration: [Kr] 4d4 5s1
Density @ 20oC: 8.57 g/cm3
Show more, including: Heats, Energies, Oxidation,
Reactions, Compounds, Radii, Conductivities
Atomic volume: 10.87 cm3/mol
Structure: bcc: body-centered cubic
Hardness: 6.0 mohs
Specific heat capacity 0.26 J g-1 K-1
Heat of fusion 26.40 kJ mol-1
Heat of atomization 733 kJ mol-1
Heat of vaporization 682.0 kJ mol-1
1st ionization energy 652.1 kJ mol-1
2nd ionization energy 1381.7 kJ mol-1
3rd ionization energy 2416 kJ mol-1
Electron affinity 86.2 kJ mol-1
Minimum oxidation number -1
Min. common oxidation no. 0
Maximum oxidation number 5
Max. common oxidation no. 5
Electronegativity (Pauling Scale) 1.6
Polarizability volume 15.7 Å3
Reaction with air w/ht, ⇒ NbO2
Reaction with 15 M HNO3 none
Reaction with 6 M HCl none
Reaction with 6 M NaOH none
Oxide(s) NbO, NbO2, Nb2O3 , Nb2O5
Hydride(s) NbH, NbH2
Chloride(s) NbCl3, NbCl4, NbCl5
Atomic radius 146 pm
Ionic radius (1+ ion) –
Ionic radius (2+ ion) –
Ionic radius (3+ ion) 86 pm
Ionic radius (1- ion) –
Ionic radius (2- ion) –
Ionic radius (3- ion) –
Thermal conductivity 53.7 W m-1 K-1
Electrical conductivity 6.6 x 106 S m-1
Freezing/Melting point: 2477 oC, 2750 K
Crystals of niobium metal

Crystals of niobium metal. Photo by Artem Topchiy.

Discovery of Niobium

Niobium was discovered in 1801 by English scientist Charles Hatchett. It was found in an American ore that had been sent to England more that a century earlier by John Winthrop the Younger, the first governor of the state of Connecticut.

Hatchett found the ore, called columbite, in the Hans Sloane collection of the British Museum.

He named the element columbium (symbol Cb).

In 1846 German chemist Henrich Rose independently discovered the element and named it niobium.

The metal was first isolated by Swedish scientist Christian Blomstrand in 1864. He reduced the chloride by heating it in a hydrogen atmosphere.

The name niobium was adopted internationally in 1950.

The element name comes from ‘Niobe’ meaning daughter of Tantalus in Greek mythology. Niobium sits directly above tantalum in the periodic table, and they share very similar chemical properties. Tantalum was named after Tantalus, father of Niobe.



Niobium

Superconducting niobium cavities, made by the Jefferson Laboratory for use in particle accelerators. (More in the video below.)

Superconducting niobium cavities from Fermilab.

Appearance and Characteristics

Harmful effects:

Some niobium compounds are highly toxic.

Characteristics:

Niobium is a shiny, white, ductile metal. In air an oxide layer forms whose color depends on its thickness. Shades of blue, green and yellow are typical.

Niobium resists corrosion due to the oxide film. The metal starts to oxidize rapidly in air at 200 oC.

Niobium’s chemical properties are very similar to those of tantalum.

Niobium is one of the five major refractory metals (metals with very high resistance to heat and wear). The other refractory metals are tungsten, molybdenum, tantalum and rhenium.

Uses of Niobium

Niobium is used with iron and other elements in stainless steel alloys and also in alloys with a variety of nonferrous metals, such as zirconium,

Niobium alloys are strong and are often used in pipeline construction.

The metal is used in superalloys for jet engines and heat resistant equipment.

Niobium is also used for jewelry. At cryogenic temperatures, niobium is a superconductor.

Abundance and Isotopes

Abundance earth’s crust: 17 parts per million by weight, 3.7 parts per million by moles

Abundance solar system: 4 parts per billion by weight, 50 part per trillion by moles

Cost, pure: $18 per 100g

Cost, bulk: $per 100g

Source: Niobium is not found free in nature but in minerals such as columbite and tantalite. Minerals that contain niobium often also contain tantalum. Commercially, niobium is extracted by first forming the oxide (Nb2O5). The oxide is then reduced using carbon or hydrogen.

Isotopes: Niobium has 28 isotopes whose half-lives are known, with mass numbers from 83 to 110. Naturally occurring niobium consists of its one stable isotope, 93Nb.
