Tungsten Element Facts

Data Zone | Discovery | Facts | Appearance & Characteristics | Uses | Abundance & Isotopes | References
74
W
183.8

The chemical element tungsten is classed as a transition metal. It was discovered in 1779 by Peter Woulfe.

Data Zone

Classification: Tungsten is a transition metal
Color: silvery-white
Atomic weight: 183.84
State: solid
Melting point: 3422 oC, 3695 K
Boiling point: 5550 oC, 5823 K
Electrons: 74
Protons: 74
Neutrons in most abundant isotope: 110
Electron shells: 2,8,18,32,12,2
Electron configuration: [Xe] 4f14 5d4 6s2
Density @ 20oC: 19.3 g/cm3
Show more, including: Heats, Energies, Oxidation,
Reactions, Compounds, Radii, Conductivities
Atomic volume: 9.53 cm3/mol
Structure: bcc: body-centered cubic
Hardness: 7.5 mohs
Specific heat capacity 0.13 J g-1 K-1
Heat of fusion 35.40 kJ mol-1
Heat of atomization 860 kJ mol-1
Heat of vaporization 824.0 kJ mol-1
1st ionization energy 770 kJ mol-1
2nd ionization energy 1700 kJ mol-1
3rd ionization energy –
Electron affinity 78.6 kJ mol-1
Minimum oxidation number -2
Min. common oxidation no. 0
Maximum oxidation number 6
Max. common oxidation no. 6
Electronegativity (Pauling Scale) 2.36
Polarizability volume 11.1 Å3
Reaction with air w/ht, ⇒ WO3
Reaction with 15 M HNO3 none
Reaction with 6 M HCl none
Reaction with 6 M NaOH –
Oxide(s) WO2, WO3 (tungstic oxide)
Hydride(s) –
Chloride(s) WCl2, WCl4, WCl6
Atomic radius 139 pm
Ionic radius (1+ ion) –
Ionic radius (2+ ion) –
Ionic radius (3+ ion) –
Ionic radius (1- ion) –
Ionic radius (2- ion) –
Ionic radius (3- ion) –
Thermal conductivity 173 W m-1 K-1
Electrical conductivity 18.2 x 106 S m-1
Freezing/Melting point: 3422 oC, 3695 K

Discovery of Tungsten

In 1779 Irish chemist Peter Woulfe deduced the existence of a new element – tungsten – from his analysis of the mineral wolframite (an iron manganese tungstate mineral).

Tungsten was isolated as tungstic oxide (WO3) in 1781, in Sweden, by Carl W. Scheele from the mineral scheelite (calcium tungstate). However he did not have a suitable furnace to reduce the oxide to the metal.

Tungsten was finally isolated by brothers Fausto and Juan Jose de Elhuyar in 1783, in Spain, by reduction of acidified wolframite with charcoal.

The element name comes from the Swedish words ‘tung sten’ meaning heavy stone.

The chemical symbol, W, comes from the original name of the element, Wolfram.

Tungsten is one of the five major refractory metals (metals with very high resistance to heat and wear).

The Five Refractory Metals – note their close relationship in the periodic table
The other refractory metals are niobium, molybdenum, tantalum, and rhenium.

41
Nb
42
Mo
73
Ta
74
W
75
Re


Tungsten metal

Tungsten metal. Photo by Tomihahndorf.

Tungsten layers - large area telescope

The Large Area Telescope (LAT) explores cosmic rays by tracking the electrons and positrons they produce after striking layers of tungsten. Credit: NASA/Goddard Space Flight Center Conceptual Image Lab.

The halogen lamp, more properly known as the tungsten halogen lamp.

Appearance and Characteristics

Harmful effects:

Tungsten is considered to be of low toxicity.

Characteristics:

Tungsten is a very hard, dense, silvery-white, lustrous metal that tarnishes in air, forming a protective oxide coating. In powder form tungsten is gray.

The metal has the highest melting point of all metals, and at temperatures over 1650 oC also has the highest tensile strength. Pure tungsten is ductile, and tungsten wires, even of a very small diameter, have a very high tensile strength.

Tungsten is highly resistant to corrosion. It forms tungstic acid (H2WO4), or wolframic acid from the hydrated oxide (WO3) and its salts are called tungstates, or wolframates.

When present in compounds, tungsten exists mostly in the oxidation state VI.

Uses of Tungsten

Tungsten and its alloys are widely used for filaments in older style (not energy saving) electric bulbs and electronic tubes.

Tungsten is also used as the filament in halogen tungsten lamps. These lamps use halogens like bromine and iodine to prevent the tungsten filament from degrading and are therefore more energy efficient than standard incandescent light bulbs.

High speed steel (which can cut material at higher speeds than carbon steel), contains up to 18% tungsten.

Tungsten is used in heavy metal alloys because of its hardness and in high-temperature applications such as welding.

Tungsten carbide (WC or W2C) is extremely hard and is used to make drills. It is also used for jewelry because of its hardness and wear resistance.

Abundance and Isotopes

Abundance earth’s crust: 1.25 parts per million by weight, 0.1 parts per million by moles

Abundance solar system: 4 parts per billion by weight, 30 part per trillion by moles

Cost, pure: $11 per 100g

Cost, bulk: $2.95 per 100g

Source: Tungsten is not found free in nature. The principal ores of tungsten are wolframite (an iron manganese tungstate) and scheelite (calcium tungstate, CaWO3). Commercially, the metal is obtained by reducing tungsten oxide with hydrogen or carbon.

Isotopes: Tungsten has 33 isotopes whose half-lives are known with mass numbers from 158 to 190. Naturally occurring tungsten is a mixture of five isotopes and they are found in the percentages shown: 180W (0.1%), 182W (26.5%), 183W (14.3%), 184W (30.6%) and 186W (28.4%).

References

Cite this Page

For online linking, please copy and paste one of the following:

<a href="https://www.chemicool.com/elements/tungsten.html">Tungsten</a>

or

<a href="https://www.chemicool.com/elements/tungsten.html">Tungsten Element Facts</a>

To cite this page in an academic document, please use the following MLA compliant citation:

"Tungsten." Chemicool Periodic Table. Chemicool.com. 18 Oct. 2012. Web.
<https://www.chemicool.com/elements/tungsten.html>.

Comments

  1. william d says

    October 15, 2012 at 5:46 pm

    Can anybody inform me if Tungsten reacts with either conc H2SO4 or HNO3

    • Doug Stewart says

      October 15, 2012 at 6:05 pm

      Hi William, there’s little if any reaction between tungsten and these concentrated acids.

      You can read more here on page 54 of this book about Tungsten by Lassner and Schubert:

      http://books.google.com/books?id=foLRISkt9gcC&printsec=frontcover&dq=Tungsten:+Properties,+Chemistry,+Technology+of+the+Element,+Alloys,+and&cd=1&redir_esc=y

  2. Casey says

    November 5, 2012 at 2:04 am

    How can I buy tungsten and in what form?
